23825
Tapered roller bearing FAG single row
-
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30302-A, SERIES 303, D=15, D1=42, B2=14,25, BALL-BEARING STEEL, COMP:STEELItem No. 23825-101504213
- D=Internal diameter
- 15
- D1=Outside diameter
- 42
- T1=Dynamic load ratings N
- 23000
- T2=Static load ratings N
- 20500
- U=Speed limit rpm
- 21000
from €19.90plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30203-A, SERIES 302, D=17, D1=40, B2=13,25, BALL-BEARING STEEL, COMP:STEELItem No. 23825-001704012
- D=Internal diameter
- 17
- D1=Outside diameter
- 40
- T1=Dynamic load ratings N
- 18500
- T2=Static load ratings N
- 17800
- U=Speed limit rpm
- 21000
from €16.09plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30303-A, SERIES 303, D=17, D1=47, B2=15,25, BALL-BEARING STEEL, COMP:STEELItem No. 23825-101704714
- D=Internal diameter
- 17
- D1=Outside diameter
- 47
- T1=Dynamic load ratings N
- 27500
- T2=Static load ratings N
- 24500
- U=Speed limit rpm
- 18200
from €19.94plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 32004-X, SERIES 320 (ISO DIMENSIO, D=20, D1=42, B2=15, BALL-BEARING STEEL, COMP:STEELItem No. 23825-302004215
- D=Internal diameter
- 20
- D1=Outside diameter
- 42
- T1=Dynamic load ratings N
- 24000
- T2=Static load ratings N
- 28500
- U=Speed limit rpm
- 18200
from €20.27plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30204-A, SERIES 302, D=20, D1=47, B2=15,25, BALL-BEARING STEEL, COMP:STEELItem No. 23825-002004714
- D=Internal diameter
- 20
- D1=Outside diameter
- 47
- T1=Dynamic load ratings N
- 27000
- T2=Static load ratings N
- 27000
- U=Speed limit rpm
- 16800
from €17.58plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30304-A, SERIES 303, D=20, D1=52, B2=16,25, BALL-BEARING STEEL, COMP:STEELItem No. 23825-102005215
- D=Internal diameter
- 20
- D1=Outside diameter
- 52
- T1=Dynamic load ratings N
- 34000
- T2=Static load ratings N
- 32500
- U=Speed limit rpm
- 15400
from €20.25plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 32005-X, SERIES 320 (ISO DIMENSIO, D=25, D1=47, B2=15, BALL-BEARING STEEL, COMP:STEELItem No. 23825-302504715
- D=Internal diameter
- 25
- D1=Outside diameter
- 47
- T1=Dynamic load ratings N
- 26500
- T2=Static load ratings N
- 33500
- U=Speed limit rpm
- 15400
from €20.06plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30305-A, SERIES 303, D=25, D1=62, B2=18,25, BALL-BEARING STEEL, COMP:STEELItem No. 23825-102506217
- D=Internal diameter
- 25
- D1=Outside diameter
- 62
- T1=Dynamic load ratings N
- 47000
- T2=Static load ratings N
- 45500
- U=Speed limit rpm
- 12600
from €24.63plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 32006-X, SERIES 320 (ISO DIMENSIO, D=30, D1=55, B2=17, BALL-BEARING STEEL, COMP:STEELItem No. 23825-303005517
- D=Internal diameter
- 30
- D1=Outside diameter
- 55
- T1=Dynamic load ratings N
- 38500
- T2=Static load ratings N
- 46500
- U=Speed limit rpm
- 12600
from €23.01plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30206-A, SERIES 302, D=30, D1=62, B2=17,25, BALL-BEARING STEEL, COMP:STEELItem No. 23825-003006216
- D=Internal diameter
- 30
- D1=Outside diameter
- 62
- T1=Dynamic load ratings N
- 43500
- T2=Static load ratings N
- 48000
- U=Speed limit rpm
- 11900
from €21.40plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30306-A, SERIES 303, D=30, D1=72, B2=20,75, BALL-BEARING STEEL, COMP:STEELItem No. 23825-103007219
- D=Internal diameter
- 30
- D1=Outside diameter
- 72
- T1=Dynamic load ratings N
- 60000
- T2=Static load ratings N
- 61000
- U=Speed limit rpm
- 10500
from €30.34plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 32007-X, SERIES 320 (ISO DIMENSIO, D=35, D1=62, B2=18, BALL-BEARING STEEL, COMP:STEELItem No. 23825-303506218
- D=Internal diameter
- 35
- D1=Outside diameter
- 62
- T1=Dynamic load ratings N
- 45500
- T2=Static load ratings N
- 57000
- U=Speed limit rpm
- 11200
from €24.76plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30207-A, SERIES 302, D=35, D1=72, B2=18,25, BALL-BEARING STEEL, COMP:STEELItem No. 23825-003507217
- D=Internal diameter
- 35
- D1=Outside diameter
- 72
- T1=Dynamic load ratings N
- 54000
- T2=Static load ratings N
- 59000
- U=Speed limit rpm
- 9800
from €26.68plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30307-A, SERIES 303, D=35, D1=80, B2=22,75, BALL-BEARING STEEL, COMP:STEELItem No. 23825-103508021
- D=Internal diameter
- 35
- D1=Outside diameter
- 80
- T1=Dynamic load ratings N
- 73000
- T2=Static load ratings N
- 75000
- U=Speed limit rpm
- 9400
from €36.17plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 32008-XA, SERIES 320 (ISO DIMENSIO, D=40, D1=68, B2=19, BALL-BEARING STEEL, COMP:STEELItem No. 23825-304006819
- D=Internal diameter
- 40
- D1=Outside diameter
- 68
- T1=Dynamic load ratings N
- 53000
- T2=Static load ratings N
- 71000
- U=Speed limit rpm
- 9800
from €28.47plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30208-A, SERIES 302, D=40, D1=80, B2=19,75, BALL-BEARING STEEL, COMP:STEELItem No. 23825-004008018
- D=Internal diameter
- 40
- D1=Outside diameter
- 80
- T1=Dynamic load ratings N
- 61000
- T2=Static load ratings N
- 67000
- U=Speed limit rpm
- 8800
from €32.09plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30308-A, SERIES 303, D=40, D1=90, B2=25,25, BALL-BEARING STEEL, COMP:STEELItem No. 23825-104009023
- D=Internal diameter
- 40
- D1=Outside diameter
- 90
- T1=Dynamic load ratings N
- 91000
- T2=Static load ratings N
- 102000
- U=Speed limit rpm
- 7800
from €44.47plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 32009-XA, SERIES 320 (ISO DIMENSIO, D=45, D1=75, B2=20, BALL-BEARING STEEL, COMP:STEELItem No. 23825-304507520
- D=Internal diameter
- 45
- D1=Outside diameter
- 75
- T1=Dynamic load ratings N
- 61000
- T2=Static load ratings N
- 86000
- U=Speed limit rpm
- 8800
from €32.66plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30309-A, SERIES 303, D=45, D1=100, B2=27,25, BALL-BEARING STEEL, COMP:STEELItem No. 23825-104510025
- D=Internal diameter
- 45
- D1=Outside diameter
- 100
- T1=Dynamic load ratings N
- 96000
- T2=Static load ratings N
- 108000
- U=Speed limit rpm
- 6700
from €56.65plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 32010-X, SERIES 320 (ISO DIMENSIO, D=50, D1=80, B2=20, BALL-BEARING STEEL, COMP:STEELItem No. 23825-305008020
- D=Internal diameter
- 50
- D1=Outside diameter
- 80
- T1=Dynamic load ratings N
- 64000
- T2=Static load ratings N
- 93000
- U=Speed limit rpm
- 7800
from €38.99plus sales taxplus shipping costsMore details -
TAPERED ROLLER BEARING FAG, SINGLE ROW W. CAGE, 30310-A, SERIES 303, D=50, D1=110, B2=29,25, BALL-BEARING STEEL, COMP:STEELItem No. 23825-105011027
- D=Internal diameter
- 50
- D1=Outside diameter
- 110
- T1=Dynamic load ratings N
- 130000
- T2=Static load ratings N
- 148000
- U=Speed limit rpm
- 6300
from €69.01plus sales taxplus shipping costsMore details
Description
Material
Inner ring, outer ring and rolling elements, bearing steel.
Cage, steel.
Cage, steel.
Version
Series 302
Series 303
Series 320 (ISO dimension)
Series 303
Series 320 (ISO dimension)
Note
Tapered roller bearings can accept high radial and axial loads. Axial loads are absorbed in only one direction. For axial counter support a second bearing mounted inverse is required. Suitable for medium speeds.
The bearings are separable. This means the bearing parts can be fitted independently of each other. The bearings are supplied without seals. They can be lubricated with grease or oil from the side.
The main dimensions of the tapered roller bearings conform to DIN ISO 355 and DIN 720. Dimensional and running tolerances correspond to tolerance class PN acc. to DIN 620. These tolerance classes are standard and are well suited for most applications.
The bearings are separable. This means the bearing parts can be fitted independently of each other. The bearings are supplied without seals. They can be lubricated with grease or oil from the side.
The main dimensions of the tapered roller bearings conform to DIN ISO 355 and DIN 720. Dimensional and running tolerances correspond to tolerance class PN acc. to DIN 620. These tolerance classes are standard and are well suited for most applications.
Temperature range
-30 °C to +120 °C.
